How to Clean Up Unattached Disks in Azure Red Hat OpenShift (ARO)
Managing storage resources efficiently is crucial to avoid unexpected costs. One common issue is the hidden accumulation of unattached disks in Azure due to the `Retain` reclaim policy in PersistentVolumes (PVs). In this post, we’ll share our experience with this problem and provide the steps to take back control over unused disks.
The Problem: hundreds of Unattached Disks
During our migration to ARO, we frequently recreated disks during development, using a custom storage class with `reclaimPolicy: Retain` to prevent accidental deletion of PersistentVolumes (PVs). This worked as expected: deleting a PersistentVolumeClaim (PVC) in OpenShift marked the PV as `Released`, but the underlying Azure disk remained intact, even after deleting the associated PV.
Months later, our manager flagged unexpectedly high Azure storage costs. We discovered hundreds of unattached disks lingering in Azure. It seems that the `Retain` policy prevented automatic deletion of the Azure disks. To make matters worse, our team lacked the necessary Azure permissions to manually delete them.
Solution: manually set persistentVolumeReclaimPolicy to Delete in PV
-> Existing PVs
If the PVC was deleted but the PV still exists in OpenShift, the fix is straightforward:
- Verify the PV is no longer needed to avoid accidental data loss
- Edit the PV’s YAML to change
persistentVolumeReclaimPolicyfromRetaintoDelete - Delete the PV in OpenShift, which will also remove the underlying Azure disk
-> Handle Orphaned Disks
If both the PVC and PV are gone, but the Azure disk remains, we need to create a new PV and PVC to bind to the disk and then delete it:
- Identify the unattached disk in Azure (e.g., via Azure Portal or CLI:
az disk list --query "[?managedBy==null]") - Create a storage class with
reclaimPolicy: Delete - Create a PV pointing to the Azure disk
- Create a PVC to bind to the PV
- Delete the PVC, which will delete the PV and the Azure disk
When all connections in OpenShift towards the Azure disk are gone, a new PV and PVC has to be created, pointing to that disk. Just use or create a storageClass similar but with reclaimPolicy set to Delete. Below are some examples.
Example PV (pv-to-delete.yaml)
kind: PersistentVolume
apiVersion: v1
metadata:
name: pv-to-delete
annotations:
pv.kubernetes.io/provisioned-by: disk.csi.azure.com
spec:
capacity:
storage: 1Gi
csi:
driver: disk.csi.azure.com
volumeHandle: /subscriptions/eae2918f-edf0-4d65-bc8c-5d4f0662d5f0/resourceGroups/aro-infra-my-cluster-name/providers/Microsoft.Compute/disks/pvc-6348c859-9577-4fd5-88f9-ebfc019eb428
fsType: ext4
volumeAttributes:
csi.storage.k8s.io/pv/name: pvc-6348c859-9577-4fd5-88f9-ebfc019eb428
csi.storage.k8s.io/pvc/name: pvc-to-delete
csi.storage.k8s.io/pvc/namespace: my-namespace
requestedsizegib: '1'
accessModes:
- ReadWriteOnce
persistentVolumeReclaimPolicy: Delete
storageClassName: my-managed-csi-premium-with-reclaimpolicy-delete
volumeMode: FilesystemExample PVC (pvc-to-delete.yaml)
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
name: pvc-to-delete
namespace: my-namespace
annotations:
pv.kubernetes.io/bind-completed: 'yes'
pv.kubernetes.io/bound-by-controller: 'yes'
volume.beta.kubernetes.io/storage-provisioner: disk.csi.azure.com
volume.kubernetes.io/storage-provisioner: disk.csi.azure.com
finalizers:
- kubernetes.io/pvc-protection
spec:
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 1Gi
volumeName: pv-to-delete
storageClassName: my-managed-csi-premium-with-reclaimpolicy-delete
volumeMode: Filesystem
status:
phase: Bound
accessModes:
- ReadWriteOnce
capacity:
storage: 1GiThis time, after the PV is bounded to the azure disk, simply delete the PVC. The corresponding PV and the Azure disk will be deleted successfully.
